Lens Compression and Perspective Exaggeration

Hello everyone!  This time I want to tackle a subject that regularly comes up in classes and coursework.  It’s also a topic on the Internet with a variety of fascinating ideas. We often hear of lens compression and as Lee Morris recently demonstrated on Petapixel. it actually does not exist.  I don’t agree with some of his terminology, but the approach is bang on.

What Is Lens Compression?

Often when we read an article or take a class there will be a section on the deliverables of different focal length lenses and invariably at some point the terminology of lens compression comes up.  While it doesn’t really exist, it sure looks like it might, so let’s tackle the subject. Lens compression looks like the distance between near and distant subjects in the frame is reduced.  You will read many photographers say they like the “compression” delivered by a telephoto lens for portraits or the lack of “compression” in a wide-angle lens for landscapes.   The words make sense because of what we see, but we are not seeing any compression, instead we are seeing perspective exaggeration.

Is This Distortion?

It’s not distortion because the lens is actually rendering exactly what it sees.  Distortion means a misrepresentation of reality such as we see in a fisheye lens or a poorly built wide-angle lens where the edges curve in. We could get into a big semantics argument, but for the purpose of the article we are going to refer to this as perspective exaggeration.  This is the correct way to refer to this subject.

Angle of View

Every focal length on a sensor of some size produces a diagonal angle of view.  When we hear about crop factor, this is the net effect. Thus, a full frame Canon camera with a lens at 70mm has a diagonal angle of view of just over 34 degrees.  If we use a Canon camera with a crop sensor, to achieve the same angle of view on the smaller sensor we would use a focal length of 44mm.  The final image looks the same and that’s the goal.  There is a much more in-depth article on this subject here.

The Lens Counter Mat

What is very interesting is how perception differs from reality.  Back in the olden days when I first worked part time in a camera store, the manufacturers provided counter mats to protect the cameras and the glass countertops.  I haven’t seen one in a long time.  One of the most useful counter mats was the lens mat.  The manufacturer would shoot the same scene, with the same camera and the same camera to subject distance with all of their lenses, and then put the pictures side by side.  The purpose, was to show how focal length impacted angle of view.

What was obvious then is still true today.  While different lenses of different focal lengths have different angles of view, there is no perspective exaggeration so long as the camera to subject distance does not change.  The background does not get closer as longer lenses are used, and It does not get pushed away when shorter focal length lenses are used.

 This image shows when the distance between the camera and the subject is fixed, there is no perspective exaggeration even when focal lengths are changed

This image shows when the distance between the camera and the subject is fixed, there is no perspective exaggeration even when focal lengths are changed

As can be seen in the sample image, when the camera to subject distance does not change, there is no impression of compression, or perspective exaggeration, we just see different angles of view depending on the lens used.  This example was shot on a Full Frame camera with a 14mm prime lens and the angle of view rectangles added after the fact using proper percentages based on angle of view in Photoshop.

When Does Perspective Exaggeration Occur?

This will occur on any lens when the camera to subject distance is very short and the depth of the subject is equal to or greater than the camera to front of subject distance. Folks believe that wide angle lenses are horrible for portraits, and they will be if you fill the frame with the person’s head, because you will be creating very short camera to subject distances and have as much depth to the head as you have distance.  This makes noses protrude and ears shrink.  You’ve seen this in most all smartphone selfies. In most all cases it’s horrible. Back off a bit and the exaggeration vanishes.

 A moderate wide angle enhances the front end of the car

A moderate wide angle enhances the front end of the car

In this example image, the car was shot from a medium low perspective with a 35mm lens on a full frame camera.  There is some perspective exaggeration but it is not excessive.

You can use perspective exaggeration to creative effect.  We see this a lot in some automotive work where a low angle, a wide lens and close positioning is used to accentuate the size, length and visual power of a car.

 In this example a 16mm lens was used very close in creating perspective exaggeration.  The perspective is exaggerated, but there is NO distortion

In this example a 16mm lens was used very close in creating perspective exaggeration.  The perspective is exaggerated, but there is NO distortion

Since the camera to subject distance was much less than the subject depth we get a significant exaggeration of the vehicle style and apparent size.

We also see it when a longer focal length lens is used in very close where the camera to subject distance is significantly greater than the depth of the scene and the very narrow angle of view serves to make it appear that the background is closer than it is.  If we were to shoot the same scene from the same place with a wide-angle lens and then crop in to deliver the same angle of view as the telephoto lens, we would see exactly the same image as with the telephoto.

Conclusions

Thus, while what we typically call lens compression doesn’t actually exist and what we think we see is perspective exaggeration, that doesn’t make the effect less useful if used with intent.  A long focal length lens shot down a city street makes it appear busier and more stacked up.  A wide-angle view of the Grand Canyon makes it look more massive with the far edge further away than it actually is because of the wider angle of view.
